Advanced caching

• Caching content with the reverse-proxy

Advanced caching (also called Expert mode) gives each website its own dedicated on-disk cache inside the reverse-proxy, driven by your own rules.

Instead of a single global on/off switch, you decide how long content stays cached, which parts of the site must never be cached (administration areas, APIs, shopping carts), and which files should be cached harder by the visitor browser (images, style sheets, scripts).

Pages served from the cache are returned by the reverse-proxy itself: your backend server is never contacted, so the response is faster and the backend load drops.

Benefits

• Less load on your backend.
  Every cache hit is a request your application server never sees. A site serving thousands of identical pages per minute can end up sending only a handful of requests to the backend.

• Faster pages for your visitors.
  A cached response is read from the local disk cache and returned immediately, without the network round-trip to the backend, the application runtime, or the database query behind it.

• Your site stays up when the backend fails.
  With Serve stale content on backend error enabled, the reverse-proxy keeps answering with the last known good copy while the backend is down, timing out, or returning 5xx errors. Visitors see a working site instead of an error page.

• Per-site isolation.
  Each website gets its own cache zone, its own directory and its own size limit. One busy site cannot evict the cached content of another.

• Surgical control.
  Rules are evaluated per URL, so you can cache the public part of a site aggressively while guaranteeing that the administration area, the API or the checkout process is never cached.

• Safe by default.
  Only GET and HEAD requests are eligible. Requests carrying an Authorization header always bypass the cache, and a response that sets a cookie is never stored. The cache respects what your backend asks for unless you explicitly override it.

• Browser-side caching too.
  Over-cache rules set the Cache-Control header sent to the visitor, so static assets are kept by the browser and are not requested again at all.

Use cases

Opening the Advanced caching panel

Open Web services, select the website you want to tune, select Optimization and click on  Caching — Expert mode panel.

The panel is organised in three tabs: the general settings, the exclusions, and the over-cache rules.

1. General parameters

This tab controls the cache zone itself.

Click the edit icon on the Time to live row to set the value and its unit:

How long a cached response stays valid before the reverse-proxy asks the backend for a fresh copy

2. Exclusions — content that must never be cached

A request matching any enabled exclusion rule is never served from the cache and is never stored in it:  it always reaches the backend.

Use this tab for everything that is personalised, authenticated or sensitive.

• Click New item to add a rule:

In the table, click the Enabled label to switch a rule on or off, click the pattern to edit it, and use the red icon to delete it.

3. Over-cache — caching harder

tell the visitor browser to keep them for a long time.

Over-cache rules target files that almost never change — images, style sheets, scripts, fonts.
The browser then stops requesting them altogether, which removes traffic both from the reverse-proxy and from your backend.

The form is the same as for exclusions, with one extra field: the time to live in minutes applied to the matching files.

Rules are evaluated in creation order and the first one that matches a URL wins.

What over-cache does exactly. A matching request gets its Cache-Control header rewritten to public, max-age=<your TTL> before the response is sent to the visitor, so the browser keeps the file for that duration.

On the server side the response is still stored according to the general Time to live of the site and to the cache headers returned by your backend: a response that the backend marks as no-store, private, or that sets a cookie, is not stored by the reverse-proxy. Over-cache never overrides that decision.

What is never cached

Independently of your rules, the reverse-proxy refuses to serve or store a cached response in the following cases. These guards exist to protect personalised content:

• The request is not a GET or a HEAD (a form submission, an upload, a deletion, …).
• The request carries an Authorization header. A shared cache must never reuse a response that was built for one authenticated user, and the cache key does not include the identity of the visitor.
• The response sets a cookie, or the backend marks it as no-store or private.
• The URL matches one of your exclusion rules.
• The request carries ?purge=1 (see below).

Important. Cached content is shared between all visitors of the website. Session cookies and the Authorization header are handled automatically, but an application that personalises a page using another mechanism — a custom header, a query parameter, the client IP address — must have those URLs added to the Exclusions tab. When in doubt, exclude first and measure afterwards.

Testing and troubleshooting

• Bypass the cache for one request.
  Add ?purge=1 to the URL: the request is forced to the backend and its answer is not stored. Useful to compare a cached page with a fresh one.

• Check that a page is cached.
  Request the same URL twice and compare the response time; a cache hit is answered by the reverse-proxy and is typically an order of magnitude faster.

• Check the browser TTL of an over-cached file.
  Look at the Cache-Control header of the response: it must show public, max-age= followed by your rule TTL expressed in seconds (a 60-minute rule gives max-age=3600).

• A page is cached and should not be.
  Add an exclusion rule in Path mode. Remember that a rule applies to the beginning of the URL, so /account covers the whole personalised area.

• Nothing seems cached.
  Verify that the feature is enabled in the first tab, that the URL does not match an exclusion rule, and that your backend does not return Cache-Control: no-store or a cookie on every response.

• Reclaim disk space.
  Lower the maximum cache size or the inactive time; entries are removed automatically.

Good to know

• Every change made in this panel rebuilds the configuration of the website and reloads the reverse-proxy.
  The operation is transparent for the visitors: established connections are not interrupted.

• Disabling the feature removes the cache directory of the website and its generated files.

• The rules belong to the website: duplicating a site does not copy them, and they are included in the configuration backups.

• Cache entries are stored per scheme, host, URL and query string: http:// and https://, and two different domains of the same site, never share an entry.
